Massive Online Analysis (MOA) provides algorithms for classification, regression, clustering, and recommendations. It also provides libraries for outlier detection and drift detection. It is designed for real-time processing on a stream of produced data.

Weka Example:

We are going to use a small diabetes dataset. We will first load the data using Weka:

import weka.core.Instances;
import weka.core.converters.ConverterUtils.DataSource;

public class Main {

    public static void main(String[] args) throws Exception {
        // Specifying the datasource
        DataSource dataSource = new DataSource("data.arff");
        // Loading the dataset
        Instances dataInstances = dataSource.getDataSet();
        // Displaying the number of instances
        log.info("The number of loaded instances is: " + dataInstances.numInstances());

        log.info("data:" + dataInstances.toString());
    }
}

There are 768 instances in the dataset. Let’s see how to get the number of attributes (features), which should be 9.

log.info("The number of attributes in the dataset: " + dataInstances.numAttributes());

Before building any model, we want to identify which column is the target column and see how many classes are found in this column:

// Identifying the label index
dataInstances.setClassIndex(dataInstances.numAttributes() - 1);
// Getting the number of
log.info("The number of classes: " + dataInstances.numClasses());

After loading the dataset and identifying our target attribute, the time now is for building the model. Let’s make a simple tree classifier, J48.

// Creating a decision tree classifier
J48 treeClassifier = new J48();
treeClassifier.setOptions(new String[] { "-U" });
treeClassifier.buildClassifier(dataInstances);

In the three lines above, we specified an option to indicate an unpruned tree and provided the data instances for model training. If we print the tree structure of the generated model after training, we can follow how the model internally built its rules:

plas <= 127
|   mass <= 26.4
|   |   preg <= 7: tested_negative (117.0/1.0)
|   |   preg > 7
|   |   |   mass <= 0: tested_positive (2.0)
|   |   |   mass > 0: tested_negative (13.0)
|   mass > 26.4
|   |   age <= 28: tested_negative (180.0/22.0)
|   |   age > 28
|   |   |   plas <= 99: tested_negative (55.0/10.0)
|   |   |   plas > 99
|   |   |   |   pedi <= 0.56: tested_negative (84.0/34.0)
|   |   |   |   pedi > 0.56
|   |   |   |   |   preg <= 6
|   |   |   |   |   |   age <= 30: tested_positive (4.0)
|   |   |   |   |   |   age > 30
|   |   |   |   |   |   |   age <= 34: tested_negative (7.0/1.0)
|   |   |   |   |   |   |   age > 34
|   |   |   |   |   |   |   |   mass <= 33.1: tested_positive (6.0)
|   |   |   |   |   |   |   |   mass > 33.1: tested_negative (4.0/1.0)
|   |   |   |   |   preg > 6: tested_positive (13.0)
plas > 127
|   mass <= 29.9
|   |   plas <= 145: tested_negative (41.0/6.0)
|   |   plas > 145
|   |   |   age <= 25: tested_negative (4.0)
|   |   |   age > 25
|   |   |   |   age <= 61
|   |   |   |   |   mass <= 27.1: tested_positive (12.0/1.0)
|   |   |   |   |   mass > 27.1
|   |   |   |   |   |   pres <= 82
|   |   |   |   |   |   |   pedi <= 0.396: tested_positive (8.0/1.0)
|   |   |   |   |   |   |   pedi > 0.396: tested_negative (3.0)
|   |   |   |   |   |   pres > 82: tested_negative (4.0)
|   |   |   |   age > 61: tested_negative (4.0)
|   mass > 29.9
|   |   plas <= 157
|   |   |   pres <= 61: tested_positive (15.0/1.0)
|   |   |   pres > 61
|   |   |   |   age <= 30: tested_negative (40.0/13.0)
|   |   |   |   age > 30: tested_positive (60.0/17.0)
|   |   plas > 157: tested_positive (92.0/12.0)Number of Leaves  :  22Size of the tree :  43

Deeplearning4j Example:

This example will build a Convolution Neural Network (CNN) model to classify the MNIST library. If you are not familiar with MNIST or how the CNN works to classify the handwritten digits, I recommend you have a quick look at my earlier post, which describes these aspects in detail.

As always, we will load the dataset and display its size.

DataSetIterator MNISTTrain = new MnistDataSetIterator(batchSize,true,seed);
DataSetIterator MNISTTest = new MnistDataSetIterator(batchSize,false,seed);

Let double check if we get ten unique labels from the dataset:

log.info("The number of total labels found in the training dataset " + MNISTTrain.totalOutcomes());
log.info("The number of total labels found in the test dataset " + MNISTTest.totalOutcomes());

Next, let’s configure the architecture of the model. We will use two convolution layers plus a flattened layer for the output. Deeplearning4j has several options that you can use to initialize the weight scheme.

// Building the CNN model
MultiLayerConfiguration conf = new NeuralNetConfiguration.Builder()
        .seed(seed) // random seed
        .l2(0.0005) // regularization
        .weightInit(WeightInit.XAVIER) // initialization of the weight scheme
        .updater(new Adam(1e-3)) // Setting the optimization algorithm
        .list()
        .layer(new ConvolutionLayer.Builder(5, 5)
                //Setting the stride, the kernel size, and the activation function.
                .nIn(nChannels)
                .stride(1,1)
                .nOut(20)
                .activation(Activation.IDENTITY)
                .build())
        .layer(new SubsamplingLayer.Builder(PoolingType.MAX) // downsampling the convolution
                .kernelSize(2,2)
                .stride(2,2)
                .build())
        .layer(new ConvolutionLayer.Builder(5, 5)
                // Setting the stride, kernel size, and the activation function.
                .stride(1,1)
                .nOut(50)
                .activation(Activation.IDENTITY)
                .build())
        .layer(new SubsamplingLayer.Builder(PoolingType.MAX) // downsampling the convolution
                .kernelSize(2,2)
                .stride(2,2)
                .build())
        .layer(new DenseLayer.Builder().activation(Activation.RELU)
                .nOut(500).build())
        .layer(new OutputLayer.Builder(LossFunctions.LossFunction.NEGATIVELOGLIKELIHOOD)
                .nOut(outputNum)
                .activation(Activation.SOFTMAX)
                .build())
        // the final output layer is 28x28 with a depth of 1.
        .setInputType(InputType.convolutionalFlat(28,28,1))
        .build();

Once the architecture is set, we need to initialize the mode, set the training dataset, and trigger the model training.

MultiLayerNetwork model = new MultiLayerNetwork(conf);
// initialize the model weights.
model.init();

log.info("Step2: start training the model");
//Setting a listener every 10 iterations and evaluate on test set on every epoch
model.setListeners(new ScoreIterationListener(10), new EvaluativeListener(MNISTTest, 1, InvocationType.EPOCH_END));
// Training the model
model.fit(MNISTTrain, nEpochs);

During the training, the score listener will provide the confusion matrix of the classification accuracy. Let’s see the accuracy after ten epochs of training:

=========================Confusion Matrix=========================
    0    1    2    3    4    5    6    7    8    9
---------------------------------------------------
  977    0    0    0    0    0    1    1    1    0 | 0 = 0
    0 1131    0    1    0    1    2    0    0    0 | 1 = 1
    1    2 1019    3    0    0    0    3    4    0 | 2 = 2
    0    0    1 1004    0    1    0    1    3    0 | 3 = 3
    0    0    0    0  977    0    2    0    1    2 | 4 = 4
    1    0    0    9    0  879    1    0    1    1 | 5 = 5
    4    2    0    0    1    1  949    0    1    0 | 6 = 6
    0    4    2    1    1    0    0 1018    1    1 | 7 = 7
    2    0    3    1    0    1    1    2  962    2 | 8 = 8
    0    2    0    2   11    2    0    3    2  987 | 9 = 9

Mallet Example:

As mentioned earlier, Mallet is a powerful toolkit for natural language modeling. We will use a sample corpus provided by the tool David Blei in Mallet package. Mallet has a specific library for annotating textual tokens for classification. Before we load our dataset, Mallet has this concept of pipeline definition where you define your pipeline and then provide the dataset to pass through.

ArrayList<Pipe> pipeList = new ArrayList<Pipe>();

The pipeline is defined as an “ArrayList,” which would contain typical steps that we always do before building a topic model. Each text in the document would pass the following steps:

1. Lowercase keywords
2. Tokenize text
3. Remove stopwords
4. Map to features

pipeList.add( new CharSequenceLowercase() );
pipeList.add( new CharSequence2TokenSequence(Pattern.compile("\\p{L}[\\p{L}\\p{P}]+\\p{L}")) );
// Setting the dictionary of the stop words
URL stopWordsFile = getClass().getClassLoader().getResource("stoplists/en.txt");
pipeList.add( new TokenSequenceRemoveStopwords(new File(stopWordsFile.toURI()), "UTF-8", false, false, false) );

pipeList.add( new TokenSequence2FeatureSequence() );

Once the pipeline is defined, we will pass the instances representing an original text of each document.

InstanceList instances = new InstanceList (new SerialPipes(pipeList));

Now the step comes to pass the input file to fill up the instance list.

URL inputFileURL = getClass().getClassLoader().getResource(inputFile);
Reader fileReader = new InputStreamReader(new FileInputStream(new File(inputFileURL.toURI())), "UTF-8");
instances.addThruPipe(new CsvIterator (fileReader, Pattern.compile("^(\\S*)[\\s,]*(\\S*)[\\s,]*(.*)$"),
        3, 2, 1)); // data, label, name fields

From the last command line, you can notice that we provided instructions on how the CSV file is structured. The source file, available in the resources folder, has around two thousand rows. Each line represents an original document text and consists of three attributes separated by comma (Name, label, and document content). We can print the number of instances found in the input document using the following command:

log.info("The number of instances found in the input file is: " + instances.size());

Now, let’s model the document’s topics. Let’s assume that we have 100 different topics in those 2k documents. Mallet enables us to set two variables: alpha and beta weights. Alpha controls the topic-word distributions’ concentration, and beta represents the pre-word weights over the topic-word distributions.

int numTopics = 100;// defining the model
ParallelTopicModel model = new ParallelTopicModel(numTopics, 1.0, 0.01);
// adding the instances to the model
model.addInstances(instances);

The model we choose in this example is an implementation of LDA (Latent Dirichlet allocation). The algorithm uses a group of observed keywords similarity to classify documents.

One of the things I like about Mallet is the API capabilities to design your parallel processing easily. Here, we can define multithread processing for each subsample.

model.setNumThreads(2);

We only two things left now is defining the number of iterations for the model training and get the training started.

model.setNumIterations(50);
model.estimate();

I left more details on how to display the topic modeling result in the full example on github.
